Cable VVG-P-0.66 white 3x1.5 power copper EUROPAN CABLE (56994)

Description

Cable VVG-P-0.66 white 3x1.5 power copper EUROPAN CABLE. VVG-P – Power cable with copper conductors, polyvinyl chloride insulation and sheath, flat. Scope of application It is designed for transmission and distribution of electrical energy in stationary installations for a rated alternating voltage of 0.66; 1 kV frequency 50 Hz. It is most preferable to use flat cables in hidden wiring and when laying alone in rectangular cable ducts of appropriate sizes, not recommended for laying in the ground (trenches). Design Conductive conductors are copper, single-wire (class 1 DSTU EN 60228), located in the same plane parallel to each other. Insulation and sheath – polyvinyl chloride plastic. Operation The cable is designed for stationary operation at ambient temperatures from -50 to +50°C, relative humidity up to 98% at temperatures up to 35°C, including for laying outdoors. The cable can be laid without preheating at a temperature not lower than -15°C. The minimum bending radius during installation should be at least 10 minimum external dimensions of the cable. The long-term permissible heating temperature of cable cores during operation is 70°C and the maximum permissible temperature at short-circuit currents is 160°C. Permissible heating of cable cores in emergency mode is not more than 80°C.
