GDP cable 2x2.5 mounting EUROPAN CABLE (2369)
GDP cable 2x2.5 mounting EUROPAN CABLE (2369)
Ready to ship
Article: 2369
Minimum order amount from 300 UAH
48 ₴
Features
Brand
Armor
without armor
Cable type
Gdpng
Cable type
Wire
Cable/wire shape
Round
Core material
Copper
All characteristics
Description
GDP cable 2x2.5 mounting EUROPAN CABLE. VVP – wire with copper conductors, polyvinyl chloride insulation and sheath. Scope Designed for transmission and distribution of electrical energy in stationary installations at a nominal alternating voltage of 380/660 or direct voltage up to 1000 V. Used for installation of electrical circuits in walls, hollow channels of building structures, on boards, for laying in plaster in damp or dry rooms, for installation of lighting and power networks. Design Conductor conductors - copper, single-wire (class 1 DSTU EN 60228), located in the same plane parallel to each other. Core insulation and sheath - polyvinyl chloride plastic compound. Operation The wire is designed for stationary operation at ambient temperatures from -40°C to +40°C. The wire can be laid without preheating at a temperature not lower than - 15°C. The minimum bending radius during installation must be at least 10 of the smallest external dimensions of the wire. The permissible continuous heating temperature of the wire cores during operation is 70°C.Benefits and warranty
High quality
The equipment is manufactured by leading European manufacturers, using modern technologies and materials.
Professional support
Our specialists are always ready to provide qualified advice and assistance in choosing equipment. We also offer a full range of services from installation to maintenance and repair.
Competitive prices
Direct contracts with manufacturers allow us to offer competitive prices for all equipment. You will receive high quality at the best price.
Returns and Exchanges
We provide the opportunity to return or exchange the product within 14 days after purchase if it does not fit or has defects.
Delivery
Nova Poshta
By courier in Kiev
Pickup in Kyiv 1A Academician Korolev Avenue9
Оплата
Payment in cash
Payment Apple Pay / Google Pay
Payment by installments Monobank
Payment online Visa / MasterCard
Payment by card - Cash on delivery "Nova Poshta"
Features GDP cable 2x2.5 mounting EUROPAN CABLE (2369)
Armor
without armor
Cable type
Gdpng
Cable type
Wire
Cable/wire shape
Round
Core material
Copper
All characteristics
Reviews (0)
There are no reviews for this product.
Buy together with GDP cable 2x2.5 mounting EUROPAN CABLE (2369)
Specification GDP cable 2x2.5 mounting EUROPAN CABLE (2369)
Armor
without armor
Cable type
Gdpng
Cable type
Wire
Cable/wire shape
Round
Core material
Copper
Core type
Multi-wire
Cross-sectional area
2.5
Flame safety
DSTU 4809:2007VVG-P – PB 1ХХХХХХХ
Minimum bending radius, Dn
10 × Dn
Minimum laying temperature, °C
up to -15°C
Nominal frequency, Hz
50
Operating temperature range, °C
from -40°C to +40°C
Outer shell material
polyvinyl chloride plastic
Permissible continuous heating temperature of the cores, °C
70°c
Producing country
Ukraine
Rated AC voltage, V
0.38/0.66 kV
Screen
without screen
Shell color
White
Temperature range
installation: up to -15°C operation: from -40°C to +40°C
The number of veins
2
