Jotafan microclimate controller (TERMISTAT-6-AL-010-LCD)

Description

Microclimate controller TERMISTAT-6-AL-010-LCD + TEMPERATURE SENSOR ¶¶The TERMISTAT-6-AL-010 microclimate controller controls the operation of fans or heaters depending on temperature and time (ventilation function). It has one electronic control output with stepless power control (first section). The controller also has two 0...10 V signal outputs: the first is used to control external devices operating as the first section, the second is used to control the operation of the rotary windows (air vents).¶¶Features: ¶large, easy-to-read LCD display with voice messages in Polish. ¶temperature measurement by digital sensors, possibility of connecting up to 4 TEMP-201 sensors, one sensor included, ¶built-in one stepless control output, allowing multi-stage (100 points) speed control of single-phase fans or electric infrared heaters with a current of no more than 6 A ¶relay alarm output (NO, NC and COM contacts), 24 V, 200 mA,¶two 0...10 V signal outputs for connecting external devices (expansion modules, inverters) with the ability to set the inverted operating mode (0% = 10 V, 100% = 0 V). The first one is used to control external devices operating as the first section (e.g., expansion modules for power supply of the liquid section, inverters), the second one is used to control the operation of the rotary windows (air intakes).¶¶Functions: ¶selection of the output mode (ventilation / heating),¶changing the operating point of the section and thermal alarm with one parameter: setpoint temperature, ¶determination of minimum and maximum control of the liquid section, ¶Prohibited range - exclusion of a part of the control range of the energy-consuming liquid section and unfavorable for fans, ¶Ventilation: Setting the ventilation cycles and levels, ¶ventilation band (reducing the ventilation time when the room temperature drops below the set value), ¶alarm function, incl. from exceeding temperature thresholds (too low, too high temperature), stopping the control process, power failure, damage to the temperature measurement path, ¶differentiation of the inputs' performance characteristics in relation to the liquid section in order to create negative pressure, ¶the ability to announce an external temperature sensor (for example, to correct the alarm threshold, the temperature is too high).
