DOL 27 capacitive proximity sensor CA-P-M30-NF-CA-PNP-2-2T, 105303
DOL 27 capacitive proximity sensor CA-P-M30-NF-CA-PNP-2-2T, 105303
In stock in Europe
Article: 105303
3 490 ₴
Features
Brand
Activation distance
0 – 20 mm
Cable
4x0.26 mm² (4xAWG22)
Cable type
Ul2517
Detection speed
˂100 Hz
Direct connection without damaging the sensor
> 10 times
All characteristics
Description
The DOL 27 sensor is a 30 mm capacitive proximity sensor designed to detect loose and solid materials. The DOL 27 and iDOL 27 sensors are available in SCR, PNP and NPN output versions. The sensors are suitable for use with contactors, relays, PLCs, etc. in the agricultural and industrial sectors, in particular in enterprises for grain level measurement and effective feed level control in poultry houses, pig houses, and cowsheds. SCR output versions are available in 2-wire versions, as well as PNP and NPN in 4-wire versions. LED indicators display the state of the capacitive sensors, providing reliable monitoring of filling and emptying processes.Benefits and warranty
High quality
The equipment is manufactured by leading European manufacturers, using modern technologies and materials.
Professional support
Our specialists are always ready to provide qualified advice and assistance in choosing equipment. We also offer a full range of services from installation to maintenance and repair.
Competitive prices
Direct contracts with manufacturers allow us to offer competitive prices for all equipment. You will receive high quality at the best price.
Returns and Exchanges
We provide the opportunity to return or exchange the product within 14 days after purchase if it does not fit or has defects.
Delivery
Nova Poshta
By courier in Kiev
Pickup in Kyiv 1A Academician Korolev Avenue9
Оплата
Payment in cash
Payment Apple Pay / Google Pay
Payment by installments Monobank
Payment online Visa / MasterCard
Payment by card - Cash on delivery "Nova Poshta"
Buy together
A set of hoses with a tee for a DOL vacuum sensor, in a set
140235
Producing country: Denmark
In stock in Europe
253 ₴
Radiation shield for DOL 140245 sensors
140245
Producing country: Denmark
In stock in Europe
3 377 ₴
T-holder, universal ø30 for iDOL 27 T sensor
140018
Producing country: Denmark
In stock in Europe
500 ₴
Universal gateway, iDOL 64 (140327)
140327
Frequency: 50-60 Hz
Humidity: 10 - 90 %RH
IP protection class: Ip65
Maximum current: 500mA DC
Number of outputs: 12
Number of ports: 4 pcs M12 port
Output current: 0–24 mA to 200 mA per output
In stock in Europe
105 066 ₴
Capacitive Sensor DOL 27 CA-P-M30-NF-CA-PNP-2-2T (NO+NC)
The capacitive sensor DOL 27 CA-P-M30-NF-CA-PNP-2-2T is a high-performance sensor in a reinforced M30 housing, designed for modern automation systems based on DC power (10-30V DC). This model is the "gold standard" for connecting to industrial controllers (PLC) and climate computers.
The main advantage is the complementary output (NO + NC). The sensor has 4 wires in the cable, allowing you to receive both Make and Break signals simultaneously. Combined with a full set of settings (2T) and a large housing diameter, this is the most reliable solution for precise level control.
Advantages of the M30 PNP Model with Dual Output
- Logic Flexibility (NO/NC). You choose the sensor function during installation. The black wire gives a "Start" signal (Make), the white one — "Stop" (Break). This allows you to keep one type of sensor in stock for all tasks.
- M30 Power. The 30 mm diameter housing has a significantly larger sensitivity zone than M18. This allows the sensor to "see" through thick plastic hopper walls or ignore significant dust buildup.
- PNP Standard. Perfect compatibility with any controllers working with positive logic (Sourcing Input).
- Full Adjustment (2T). Time delay (Delay) and sensitivity (Sens) adjustments allow adapting the sensor to any conditions, from auger vibration to feed recipe changes.
Applications of DOL 27 CA-P-M30-NF-CA-PNP-2-2T
This model is recommended for critical nodes:
- Central Silos. Load level monitoring with data transmission to the central computer.
- Complex Logic Systems. Where you need to simultaneously stop one motor (NC) and turn on a signal lamp (NO).
- Harsh Conditions. Where M18 sensors fail due to wall thickness or distance to material.
Technical Specifications
| Characteristic | Value |
|---|---|
| Output Type | PNP (10-30V DC) |
| Logic | NO + NC (Complementary) |
| Housing | M30 (30 mm) |
| Settings | 2 trimmers (Sens + Time) |
Installation of DOL 27 PNP Sensor
- Connection (4 wires): Brown (+), Blue (-). Black wire — NO signal (Make). White wire — NC signal (Break).
- Installation: Fix in a 30.5 mm hole with nuts.
- Adjustment: Adjust sensitivity and delay time under the protective cap.
Comparison of 4-wire and 3-wire versions
Advantage of the NO+NC model:
| Parameter | 4 wires (This model) | 3 wires (Standard) |
|---|---|---|
| Logic Selection | Any (NO or NC) | Only one (fixed) |
| Simultaneous Signals | Possible | Impossible |
| Stock Versatility | Maximum | Low |
This is the most powerful DC sensor in the lineup.
Features DOL 27 capacitive proximity sensor CA-P-M30-NF-CA-PNP-2-2T, 105303
Activation distance
0 – 20 mm
Cable
4x0.26 mm² (4xAWG22)
Cable type
Ul2517
Detection speed
˂100 Hz
Direct connection without damaging the sensor
> 10 times
All characteristics
Reviews (6)
Тетяна
Стоїть високо під дахом на завантаженні. Взяли такий великий (М30), бо в нього і світлодіод ззаду більший. Знизу реально видно, горить він чи ні. На маленьких датчиках ту лампочку в пилюці не розгледиш, треба драбину тягнути. А тут все видно з підлоги.
09/11/2025
Володимир
Збирав саморобний пульт на дешевих китайських реле. Вони всі керуються по мінусу. Мені треба було, щоб датчик подавав саме землю на котушку. Цей NPN підійшов. Різьба велика, зручно кріпити на товсту пластикову бочку, не зривається при затяжці.
14/05/2025
Оксана
Використовуємо для тирси (підстилка). Вона легка, і пласкі датчики її не бачили, коли вона трохи налипала. У цього голова стирчить вперед (NF), він занурюється в купу і спрацьовує чітко. Таймер виставили на максимум, щоб не блимав дарма, коли тирса сиплеться нерівно.
20/01/2025
Сергій
У нас цей датчик стоїть у проході, де часто ходять люди з інструментом. Тонкі датчики (М18) ми вже два розбили випадково держаком лопати. Цей М30 товстий, масивний, його так просто не зламаєш. Для нас суто механічна міцність була головним критерієм.
25/10/2024
Андрій
Купив, бо помилився минулого разу. Взяв спочатку звичайний датчик, а він не запускає мою автоматику. Виявилося, що мій блок керування розуміє тільки "мінус" (NPN). Довелося перезамовляти цей. Поставив — все запрацювало відразу. Дивіться уважно схему перед покупкою.
18/06/2024
Buy together with DOL 27 capacitive proximity sensor CA-P-M30-NF-CA-PNP-2-2T, 105303
Universal gateway, iDOL 64 (140327)
140327
Frequency: 50-60 Hz
Humidity: 10 - 90 %RH
IP protection class: Ip65
Maximum current: 500mA DC
Number of outputs: 12
Number of ports: 4 pcs M12 port
Output current: 0–24 mA to 200 mA per output
105 066 ₴
Specification DOL 27 capacitive proximity sensor CA-P-M30-NF-CA-PNP-2-2T, 105303
Activation distance
0 – 20 mm
Cable
4x0.26 mm² (4xAWG22)
Cable type
Ul2517
Detection speed
˂100 Hz
Direct connection without damaging the sensor
> 10 times
Hysteresis
4 - 10%
IP protection class
69k (DIN 40050-9) IP | 1, 3, 4, 6, 12, 13 NEMA
Length of cable
2 m
Maximum current
500mA DC
Maximum ripple
10%
MaxRunTimer
Off / Interval 1 / Interval 2
No-load current consumption
˂6mA DC
Number of outputs
1 or 2
Output type
NO and NC
Producing country
Denmark
Reproducibility
5%
Safe activation distance
4 – 15 mm
Sensitivity
0 - 20 mm
Sensor diameter
29.5 mm
Sensor length
117 mm
Shutdown delay time
60s
Statement
CE, C-UL, UL
Supply voltage
10 - 36 V DC
Switch-on time delay
0
Temperature, storage
-40 - 80 °C
Temperature, use
-20 - +70 °C
Time delay, start
60 ms
Type
Capacitive sensor
Voltage drop
< 2.5 V DC
Weight with cable
170 g
