Axial fan, Multifan, 770 W (V6D9001M11036)

Name: Axial fan, Multifan, 770 W (V6D9001M11036)
Brand: Vostermans
SKU: V6D9001M11036
Price: 60087 UAH
Availability: InStock

In stock in Europe

Article: V6D9001M11036

Write a review

60 087 ₴

Features

Brand

Vostermans

Air volume at 0 Pa (0.00 in. wg)

20300 m3/h

Air volume at 50 Pa (0.2 in. wg)

15600 m3/h

Diameter

915 mm

Diameter, mm

915

Fan type

Wall / axial

All characteristics

Download technical documentation

Description

High performance captured in a compact design. Galvanized Box Fans are often used in buildings where a lot of ventilation is required.The box of the fan makes it easy to position the fan in a wall, and to equip your fan with add-ons such as a shutter. In addition, the Galvanized Box Fan can also be combined with light traps or air filters.

Download technical documentation

Benefits and warranty

High quality

The equipment is manufactured by leading European manufacturers, using modern technologies and materials.
Professional support

Our specialists are always ready to provide qualified advice and assistance in choosing equipment. We also offer a full range of services from installation to maintenance and repair.
Competitive prices

Direct contracts with manufacturers allow us to offer competitive prices for all equipment. You will receive high quality at the best price.
Returns and Exchanges

We provide the opportunity to return or exchange the product within 14 days after purchase if it does not fit or has defects.

Delivery

Nova Poshta
By courier in Kiev
Pickup in Kyiv 1A Academician Korolev Avenue9

Оплата

Payment in cash
Payment Apple Pay / Google Pay
Payment by installments Monobank
Payment online Visa / MasterCard
Payment by card
Cash on delivery "Nova Poshta"

Galvanised steel axial fan Multifan 92 cm 770 W

The Multifan is a reliable and high-performance fan designed to provide efficient ventilation in industrial, agricultural and commercial environments. Thanks to its galvanised steel, it is resistant to corrosion and designed for long-lasting operation even in harsh environments.

Product benefits:

High performance: Optimal diameter and capacity provide powerful airflow for large rooms.
Galvanised steel: Robust and corrosion-resistant construction ensures durability and efficiency even in humid or corrosive environments.
Versatile installation: The compact design makes it easy to integrate the fan into a wall or other ventilation systems.
Optional equipment: The fan can be fitted with louvres, light reflectors or air filters to improve functionality.
Energy efficiency: Balanced performance and low energy consumption make this fan an economical choice.

Applications:

Agriculture: Ventilation in farms, poultry farms, greenhouses.
Industry: Warehouses, production facilities, workshops.
Commercial facilities: Trading floors, logistics centres, car parks.

The Multifan galvanised steel axial fan combines power, durability and versatility, providing ideal working and storage conditions. Its design and functionality meet the highest requirements of modern ventilation systems.

Features Axial fan, Multifan, 770 W (V6D9001M11036)

Air volume at 0 Pa (0.00 in. wg)

20300 m3/h

Air volume at 50 Pa (0.2 in. wg)

15600 m3/h

Diameter

915 mm

Diameter, mm

915

Fan type

Wall / axial

All characteristics

Reviews (0)

There are no reviews for this product.

Buy together with Axial fan, Multifan, 770 W (V6D9001M11036)

Specification Axial fan, Multifan, 770 W (V6D9001M11036)

Air volume at 0 Pa (0.00 in. wg)

20300 m3/h

Air volume at 50 Pa (0.2 in. wg)

15600 m3/h

Diameter

915 mm

Diameter, mm

915

Fan type

Wall / axial

Frequency

50 Hz

Insulation Class

Cl.f

IP Class

Ip55

Material

Max. ambient temperature

40 °C

Maximum current

3.0/1.7 A

Min. ambient temperature

-25 °C

Phase

Power consumption

770 W

Rated current, A

280/160 mA

Voltage

230/400 V

Weight

42.7 kg
